WIRES

Product Range

0.5 sq mm
No of strands 16
Dia of strands (mm) 0.20
Insulation thickness (mm) 0.60
Max overall dia (mm) 2.6
Max resistance at 200c ( Ω/km) 39.0
Features
  • Class of conductor as per ISO 8130:1984 - 5
  • Current carrying capacity two cables, single phase | Bunched and enclosed in Conduit or Trunking : 4 Amps
  • Current carrying capacity two cables, single phase | On a cable tray and unenclosed : 4 Amps
0.75 sq mm
No of strands 24
Dia of strands (mm) 0.20
Insulation thickness (mm) 0.60
Max overall dia (mm) 2.8
Max resistance at 200c ( Ω/km) 26.0
Features
  • Class of conductor as per ISO 8130:1984 - 5
  • Current carrying capacity two cables, single phase | Bunched and enclosed in Conduit or Trunking : 7 Amps
  • Current carrying capacity two cables, single phase | On a cable tray and unenclosed : 7 Amps
1 sq mm
No of strands 14
Dia of strands (mm) 0.30
Insulation thickness (mm) 0.70
Max overall dia (mm) 3.2
Max resistance at 200c ( Ω/km) 18.1
Features
  • Class of conductor as per ISO 8130:1984 - 2
  • Current carrying capacity two cables, single phase | Bunched and enclosed in Conduit or Trunking : 11 Amps
  • Current carrying capacity two cables, single phase | On a cable tray and unenclosed : 12 Amps
1.5 sq mm
No of strands 22
Dia of strands (mm) 0.30
Insulation thickness (mm) 0.70
Max overall dia (mm) 3.3
Max resistance at 200c ( Ω/km) 12.1
Features
  • Class of conductor as per ISO 8130:1984 - 2
  • Current carrying capacity two cables, single phase | Bunched and enclosed in Conduit or Trunking : 13 Amps
  • Current carrying capacity two cables, single phase | On a cable tray and unenclosed : 16 Amps
2.5 sq mm
No of strands 36
Dia of strands (mm) 0.30
Insulation thickness (mm) 0.80
Max overall dia (mm) 4
Max resistance at 200c ( Ω/km) 7.41
Features
  • Class of conductor as per ISO 8130:1984 - 2
  • Current carrying capacity two cables, single phase | Bunched and enclosed in Conduit or Trunking : 18 Amps
  • Current carrying capacity two cables, single phase | On a cable tray and unenclosed : 22 Amps
4 sq mm
No of strands 56
Dia of strands (mm) 0.30
Insulation thickness (mm) 0.80
Max overall dia (mm) 4.8
Max resistance at 200c ( Ω/km) 4.95
Features
  • Class of conductor as per ISO 8130:1984 - 5
  • Current carrying capacity two cables, single phase | Bunched and enclosed in Conduit or Trunking : 24 Amps
  • Current carrying capacity two cables, single phase | On a cable tray and unenclosed : 29 Amps
6 sq mm
No of strands 84
Dia of strands (mm) 0.30
Insulation thickness (mm) 0.80
Max overall dia (mm) 5.3
Max resistance at 200c ( Ω/km) 3.30
Features
  • Class of conductor as per ISO 8130:1984 - 5
  • Current carrying capacity two cables, single phase | Bunched and enclosed in Conduit or Trunking : 31 Amps
  • Current carrying capacity two cables, single phase | On a cable tray and unenclosed : 37 Amps
10 sq mm
No of strands 140
Dia of strands (mm) 0.30
Insulation thickness (mm) 0.80
Max overall dia (mm) 7.0
Max resistance at 200c ( Ω/km) 1.91
Features
  • Class of conductor as per ISO 8130:1984 - 5
  • Current carrying capacity two cables, single phase | Bunched and enclosed in Conduit or Trunking : 42 Amps
  • Current carrying capacity two cables, single phase | On a cable tray and unenclosed : 51 Amps
